TECHNICAL SPECIFICATIONS
Type
3-way loudspeaker
Drivers
1 1/8” (28mm) soft-dome tweeter equipped with Revival Audio ARID (Anti Reflection Inner Dome) patented technology with a large back chamber and low resonance frequency of 520 Hz
3” (75mm) soft-dome mid-range equipped with ARID+ patent technology
12” (30cm) BSC (Basalt Sandwich Construction) woofer
Frequency Response (+/-3 dB)
28 Hz – 22 kHz (-3 dB)
Sensitivity
89 dB/2.83 V/1 metre
Nominal Impedance
4 ohms
Minimum Impedance
3.2 ohms at 110 Hz
Crossover Frequency
450 Hz and 3.5 kHz
Recommended Amplifier Power
Power handling: 200 watts, starting from 30-50 watts
Recommended Room Size
30 to 60 m²
Dimensions (H x W x D)
710 mm x 420 mm x 355 mm
Net Weight
33 kg (72.75 lbs)
Speaker Stands
Sold separately
