B&W ASW610XP 10-Inch 500W Subwoofer in Matte Black
Introducing the SW610XP
Proudly brought to you by Bowers & Wilkins
The ASW610XP, the most powerful of the 600 Series subwoofers, delivers the finishing touch – or finishing thump – to a hi-fi or home theatre system for larger rooms. Serious bass power is developed in a compact cabinet thanks to the unit’s
500W amplifier, long-throw 250mm driver. Equipped with audiophile-standard Class D circuitry, the unit remains cool and efficient under pressure.
In all of the 600 Series subwoofers, the bass driver diaphragms are constructed from a rugged, finely-tuned mix of paper pulp, Kevlar® fibres and resin, which provides the stiffness needed to withstand the tremendous physical forces exerted by the voice coil and pressures inside the cabinet.
Ultra-solid construction delivers slamming bass, drum kicks, and special movie effects. Deformation is minimised; bass precision, power and enjoyment are maximised.
Product Specifications:
|
Crossover Tuning |
Yes |
|
Mushrooms |
Yes |
|
Description |
Active closed-box subwoofer system |
|
Drive unit |
ø250mm (10 in) paper/Kevlar® cone long-throw |
|
Frequency range |
-6dB at 18Hz and 25/140Hz adjustable (EQ at A) |
|
Frequency response |
±3dB 25Hz – 40/140Hz adjustable (EQ at A) |
|
Bass Extension |
-6dB at 18Hz (position A) -6dB at 23Hz (position B) -6dB at 28Hz (position C) |
|
Amplifier |
Power output: 500W |
|
Rated power consumption |
98W / 1W standby |
|
Input impedance |
33kΩ |
|
Signal / noise |
>90dB |
|
Functions |
Input level (line in) Input level (speaker in) Low-pass filter frequency (line in only) Low-pass filter bypass Bass extension Bass roll-off alignment Auto sense on/standby Phase switch |
|
Inputs |
Line In (RCA Phono) Speaker in (Binding post) 12v trigger (3.5mm jack) Low-pass filter Active 4th-order, variable cut-off frequency |
|
Dimensions |
|
|
Height |
325mm (12.8 in) not including feet |
|
Width |
325mm (12.8 in) |
|
Depth |
330mm (13in) including grille and controls |
|
Net weight |
15.5kg (34.4 lb) |
|
Finishes |
|
|
Cabinet |
Black White |
|
Grille |
Black with Black Gray with White |
*This information has been obtained from Manufacturers website. We advise that Features & Specifications are subject change from Manufacturer without notice.
E&OE
