Audio Technica AT-VM510xCB Dual Moving Magnet Cartridge
"WE ASSURE YOU THAT ALL OUR PRODUCTS ARE 100% GENUINE AND COME WITH A FULL AUSTRALIAN WARRANTY."
Meet the AT-VM510xCB
Dual Moving Magnet Cartridge from Audio Technica
The AT-VMx series brings new warmth and realism to Audio-Technica’s premium dual moving magnet (MM) cartridge line, delivering an expansive soundstage that’s alive with musical detail.
Like all Audio Technica MM cartridges, this updated design closely mirrors the cutter head used to make the vinyl master. It utilises two magnets, positioned to match the left and right channels in the stereo record groove for outstanding channel separation and extended frequency response. The new VMx series also introduces material and design changes to further refine the sound, offering responsive playback that is especially sensitive to the dynamism of musical expression.
Product Features
- Conical stylus tracks the center of the record groove for reliable performance and durability
- Paratoroidal coils improve generating efficiency for enhanced channel separation, channel balance, and transient response
- PCUHD (Pure Copper Ultra High Drawability) coils – and fewer coil turns – deliver highly responsive, three-dimensional sound reproduction with excellent transient response
- Center shield plate between the left and right channels reduces crosstalk for clear stereo sound
- Threaded inserts make cartridge easier to mount, especially to integrated tonearms
- V-cut in the flip-up stylus protector shows stylus position, serving as a guide for lowering the stylus onto a record
- Durable low-resonance polymer housing
- Aluminium cantilever
- Compatible with any turntable headshell that accepts 1/2" cartridges
- Compatible with most AT-VMx series replacement styli,* offering a wide choice of options for every budget and application
Technical Specifications
Type
VM
Frequency Response
20 to 20,000 Hz
Channel Separation
24 dB (1 kHz)
Vertical Tracking Angle
20 degrees
Vertical Tracking Force Range
1.8 to 2.2 g (standard 2.0 g)
Recommended Load Impedance
47 Ohm
Coil Impedance
3.2 Ohms(1 kHz)
DC Resistance
750 ohms
Coil Inductance
480 mH (1 kHz)
Output Voltage
0.32 mV (at 1 kHz, 5 cm/sec)
Output Balance
1.5 dB (1 kHz)
Cantilever
Aluminium pipe
Static Compliance
23 × 10-6 cm/dyne
Dynamic Compliance
7 × 10-6 cm/dyne (100 Hz)
Threaded Hole
M2.6 × 2
Recommended Load Capacitance
150 to 250 pF
Replacement Stylus
AT-VMN10xCB (sold separately)*
Stylus Curvature Radius
0.6 mil
Cartridge Weight
7.2 g
Dimensions (H x W x D)
28 x 18.3 x 17.6 mm
Accessories Included
- Cartridge installation screws** (M2.6) (10.0 mm (0.39”) × 2, 8.0 mm (0.31”) × 2, 5.0 mm (0.20”) × 2)
- Washer × 2
*This information has been obtained from Manufacturers website. We advise that Price, Features & Specifications are subject change without notice.
E & O E
