Klipsch Klipschorn AK6 Floorstanding Speakers (pair)
Klipsch Klipschorn AK6 Floorstanding Speakers (pair)
KLIPSCHORN SPEAKERS
CORNER-HORN SPEAKER
The Klipschorn has truly stood the test of time. Its patented low-frequency horn boasts a unique design which uses the floor and walls of the listening room to complete the horn, increasing the low frequency extension and efficiency. The original corner-horn loudspeaker’s folded low frequency enclosure offers the most efficient use of space possible. Simply put, this is a basic design that cannot be improved according to the
laws of physics.
FULLY HORN-LOADED
The Klipschorn is the only fully horn-loaded loudspeaker available to the consumer market which is designed to operate in a corner. With its three-way system, each driver is coupled to an exponential horn and optimised to operate in its individual pass-band. This allows the Klipschorn to be a staggering 10 to 20 times more efficient than other conventional loudspeakers. Higher efficiency yields greater acoustic power, which is generated with considerably less effort from the loudspeaker’s diaphragm. The result is the cleanest, most dynamic sound possible throughout the entire musical range.
BOOK-MATCHED WOOD VENEER
Klipsch only uses book-matched wood veneers for the Heritage series. The veneer leaves are kept in order as they are delicately sliced from the timber and precisely arranged to provide a mirror image at the splice joint — like turning the pages of a book. This gives each speaker an aesthetically appealing and consistent appearance that is treasured more than any other cut of wood veneer.
MATCHED PAIRS
Each pair of Heritage series loudspeakers is grain-matched, using wood veneer panels that come from the same timber. Each cabinet is carefully matched so that each speaker in the pair is practically indistinguishable from the other. The speakers move seamlessly together through the factory, and each finished product is inspected and labeled with sequential serial numbers, ensuring that your Heritage series speaker leaves the factory as a meticulously crafted set.
BUILT TO LAST
While each and every component of the Klipschorn is built to last, Klipsch has always recognised the unique and critical role of a loudspeaker’s cabinet in the sound reproduction process. From the craftsmen in Hope, AR to the engineers in Indianapolis, IN, Klipsch has always put an extraordinary emphasis on cabinet design. Crafted from over a hundred wood panels, the Klipschorn enclosure is assembled using only the highest-grade adhesives and fasteners. This is a speaker you will hand down from generation to generation.
SPECIFICATIONS
FREQUENCY RESPONSE (+/- 4 dB) | 33Hz – 17kHz |
SENSITIVITY1 | 105dB @ 2.83V / 1m |
POWER HANDLING (CONT/PEAK) | 100W/400W |
MAXIMUM SPL | 121dB Continuous |
NOMINAL IMPEDANCE | 8 ohms Compatible |
CROSSOVER FREQUENCY | HF: 4500Hz MF: 450Hz |
HIGH FREQUENCY DRIVER | K-77-D 1” (2.54cm) Phenolic diaphragm compression driver |
MIDRANGE | K-55-X 2” (5.08cm) Phenolic diaphragm compression driver |
LOW FREQUENCY DRIVER | K-33-E 15” (38.1cm) Fiber-composite cone woofer with a trihedral exponential folded horn |
ENCLOSURE MATERIAL | Birch Plywood and MDF |
INPUTS | Dual binding posts / bi-wire / bi-amp |
HEIGHT | 50.75” (128.9.4cm) |
WIDTH | 31.25” (79.38cm) |
DEPTH | 28.25” (71.75cm) |
WEIGHT | 175lbs (79.5kg) |
FINISH | Walnut / Cherry / Black |
