Klipsch Klipschorn AK6 Floorstanding Speakers (pair)

KLIPSCHORN SPEAKERS

CORNER-HORN SPEAKER

The Klipschorn has truly stood the test of time. Its patented low-frequency horn boasts a unique design which uses the floor and walls of the listening room to complete the horn, increasing the low frequency extension and efficiency. The original corner-horn loudspeaker’s folded low frequency enclosure offers the most efficient use of space possible. Simply put, this is a basic design that cannot be improved according to the
laws of physics.

FULLY HORN-LOADED

The Klipschorn is the only fully horn-loaded loudspeaker available to the consumer market which is designed to operate in a corner. With its three-way system, each driver is coupled to an exponential horn and optimised to operate in its individual pass-band. This allows the Klipschorn to be a staggering 10 to 20 times more efficient than other conventional loudspeakers. Higher efficiency yields greater acoustic power, which is generated with considerably less effort from the loudspeaker’s diaphragm. The result is the cleanest, most dynamic sound possible throughout the entire musical range.

BOOK-MATCHED WOOD VENEER

Klipsch only uses book-matched wood veneers for the Heritage series. The veneer leaves are kept in order as they are delicately sliced from the timber and precisely arranged to provide a mirror image at the splice joint — like turning the pages of a book. This gives each speaker an aesthetically appealing and consistent appearance that is treasured more than any other cut of wood veneer.

MATCHED PAIRS

Each pair of Heritage series loudspeakers is grain-matched, using wood veneer panels that come from the same timber. Each cabinet is carefully matched so that each speaker in the pair is practically indistinguishable from the other. The speakers move seamlessly together through the factory, and each finished product is inspected and labeled with sequential serial numbers, ensuring that your Heritage series speaker leaves the factory as a meticulously crafted set.

BUILT TO LAST

While each and every component of the Klipschorn is built to last, Klipsch has always recognised the unique and critical role of a loudspeaker’s cabinet in the sound reproduction process. From the craftsmen in Hope, AR to the engineers in Indianapolis, IN, Klipsch has always put an extraordinary emphasis on cabinet design. Crafted from over a hundred wood panels, the Klipschorn enclosure is assembled using only the highest-grade adhesives and fasteners. This is a speaker you will hand down from generation to generation.

SPECIFICATIONS

FREQUENCY RESPONSE (+/- 4 dB)

33Hz – 17kHz

SENSITIVITY1

105dB @ 2.83V / 1m

POWER HANDLING (CONT/PEAK)

100W/400W

MAXIMUM SPL

121dB Continuous

NOMINAL IMPEDANCE

8 ohms Compatible

CROSSOVER FREQUENCY

HF: 4500Hz

MF: 450Hz

HIGH FREQUENCY DRIVER

K-77-D 1” (2.54cm) Phenolic diaphragm compression driver

MIDRANGE

K-55-X 2” (5.08cm) Phenolic diaphragm compression driver

LOW FREQUENCY DRIVER

K-33-E 15” (38.1cm) Fiber-composite cone woofer with a trihedral exponential folded horn

ENCLOSURE MATERIAL

Birch Plywood and MDF

INPUTS

Dual binding posts / bi-wire / bi-amp

HEIGHT

50.75” (128.9.4cm)

WIDTH

31.25” (79.38cm)

DEPTH

28.25” (71.75cm)

WEIGHT

175lbs (79.5kg)

FINISH

Walnut / Cherry / Black


10 Year Warranty
