Engineered for pristine studio-quality sound at home, the 702 S3 Signature utilises upgraded midrange and low-frequency motor systems, improved capacitors, revised speaker terminals, plus a more open tweeter grille mesh, as developed for the B&W 800 Series Signature loudspeakers.

The 700 Series Signature models employ a series of carefully designed and engineered upgrades designed to deliver the best possible sound and visual presentation.

Aesthetically, the Signature models are finished in lustrous Midnight Blue Metallic paint or Datuk Gloss veneer, with multiple coats of paint or lacquer to deliver a supremely rich and desirable finish. Metal component parts, such as the tweeter body, are finished in Satin Black.

Drive unit pods and tweeter grilles are trimmed with a gold colour diamond cut trim bezel while Tweeter grilles adopt the same advanced design and hole pattern found on the 801 and 805 D4 Signature models. Each unit also features new brass speaker terminal posts for a cleaner signal path along with a Signature logo above the speaker terminal plate designed to highlight its exclusivity.

The Crossover is the main area of significant audio improvement over the standard models and includes the following upgrades:

• New Mundorf EVO Silver Gold Oil capacitors with Angelique wire lead-outs for High Frequencies
• New Mundorf EVO Silver Gold Oil capacitors with Angelique wire lead-outs and new Bevenbi MPAZ-E polypropylene capacitors with zinc foil for Midrange Frequencies
• New air-core inductors for Low Frequency drive units
• Upgraded poles on Mid and Low Frequency motor systems with larger venting and lower inductance
• Bypass capacitors reconfigured and located in series with each other on each board

As with all Signature technologies, none of these components will be made available for ‘retro-fit’ to current products or added as a running change into existing 700 Series S3 products

Solid Body Tweeter

The 702 S3 Signature features the latest generation of B&W’s iconic Solid Body Tweeter-on-Top housing. Its redesigned, more elongated form incorporates a longer tube-loading system to produce an even more free and open sound with high frequencies. The carefully decoupled housing is milled from a single solid block of aluminium to better resist resonance.

Carbon Dome Tweeters

Carbon Dome tweeters are purpose-built for the 700 Series. Delivering a dramatic improvement on the aluminium double dome tweeter, they raise the breakup threshold to 47kHz, for pinpoint imaging accuracy and detail.

Biomimetic Suspension

Sometimes, making a big difference takes unconventional thinking.

The transition from B&W’s famous yellow Aramid Fibre midrange cones to the Continuum cone technology resulted in a massive improvement to midrange performance. Now, B&W have turned their attention to another crucial element in a loudspeaker cone: the fabric spider. The unique Biomimetic Suspension revolutionises midrange cone performance by greatly reducing the unwanted air pressure and coloration that a conventional fabric spider can generate. The result? Midrange transparency you wouldn’t believe possible.

Continuum™ Cone

Thanks to its composite construction, the Continuum™ cone avoids the abrupt transitions in behaviour that can impair the performance of a conventional drive unit. The result is a more open, neutral performance that delivers voices and instruments with precision and transparency.

Decoupled Midrange Assembly

The 702 S3 Signature has a dedicated midrange cone using four key Bowers & Wilkins technologies: the Continuum cone, FST™, Biomimetic Suspension and midrange decoupling, the latter ensuring minimal interference from the operation of the loudspeaker’s bass drivers.

Aerofoil™ Profile Bass Cone

Developed using advanced computer modelling techniques, the Aerofoil™ Profile bass cone has variable thickness, providing stiffness and rigidity where it’s needed most. The result: deep and dynamic bass.

Curved Baffle

The 700 S3 range features a curved front baffle for the first time. This allows the midrange and bass drivers to be located in individual pod-type housings that sit proud of the speaker baffle. When combined with the curvature of the structure, this advanced approach – derived from the 800 Series Diamond – reduces the audible impact of the cabinet, creating a cleaner, more open and more immersive sound.

The 700 Series 3 Range

The Bowers & Wilkins 700 S3 range of loudspeakers is defined by elegance and driven by performance. Every model in the range is inspired by the recording studio and enabled by cutting-edge technologies first developed for B&W’s flagship 800 Series Diamond.

The 700 Series contains eight models: there’s a speaker to suit every home and every requirement, whether your passion is high-performance stereo, immersive home cinema or a mix of both. Every model combines slim, elegant proportions with a choice of exquisite finishes.

With the 700 Series 3, Studio Sound comes home.

Precision Sound

700 Series uses a wealth of state-of-the-art technologies derived from B&W’s award-winning 800 Series Diamond range to provide a best-in-class audio experience.

Bring Hollywood Home

With two centre channel speakers to choose from plus the option of matching subwoofers, in-wall and in-ceiling speakers, the 700 Series performs brilliantly in any home cinema set-up.

Meaningful Design

Thanks to its svelte proportions, premium detailing and subtly curved cabinet form – plus the option of an all new Mocha finish – the 700 Series range is both beautiful and effortlessly elegant.

Studio Sound, Your Way

This is B&W’s most extensive range: 700 Series range features floorstanding, stand mount and bookshelf speakers, meaning you can get precision sound in any size of room, however you prefer to listen.

The Bowers & Wilkins Story

The story of Bowers & Wilkins starts with one man – John Bowers. His drive and passion are written into the DNA of the company he founded over 50 years ago. Bowers dreamed of producing the perfect loudspeaker – of delivering recorded sound that is utterly faithful to the live performance and to the artist’s original intent.

B&W’s dedication to audio excellence compels them to design, develop and manufacture as many of the components that go into their products as they possibly can – because only that way can they be confident that they’ll achieve the performance and quality they demand from everything they do, whatever the product category.

For B&W, it’s a love affair rooted in the very fabric of music and film sound. For decades, Bowers & Wilkins loudspeakers have been the trusted choice of studio professionals and recording artists the world over, from Abbey Road Studios to Skywalker Sound.

Today, B&W produce an extensive range of quality audio visual products from speakers to subwoofers, headphones to soundbars. No matter what sort of sound reproduction you’re after, Bowers & Wilkins probably have the perfect product for you.

Technical Specifications

Drive units
1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
1x ø150mm (6 in) Continuum cone FST midrange
3x ø165mm (6.5 in) Aerofoil Profile bass

Frequency range
-6dB 28Hz - 33kHz

Frequency response
46Hz - 28kHz ±3dB

Harmonic distortion
2nd and 3rd harmonics (90dB, 1m on axis)

• <1% 86Hz - 28kHz
• <0.5% 110Hz - 20kHz

Nominal impedance
8Ω (minimum 3.1Ω)

Recommended amplifier power
30W - 300W into 8Ω on unclipped programme

Sensitivity
90dB spl (2.83Vrms, 1m)

Technical features
Decoupled Carbon Dome tweeter
Solid Body Tweeter-on-Top
Continuum™ cone FST™ midrange
Decoupled midrange
Aerofoil™ Profile bass cones
Flowport™

Description
3-way vented-box system

Max recommended cable impedance
0.1Ω

Datum Gloss
Midnight Blue Metallic

Grille finish
Black

Dimensions

Net weight
35.26 kg (77.7 lbs)

Warranty
5 Years Manufacturers Warranty



*This information has been obtained from Manufacturers website. We advise that Features, Specifications & Price are subject change from Manufacturer without notice.
