Arcam A5 Integrated Amplifier

Arcam A5 Integrated Amplifier

Regular price $1,495.00 AUD
Regular price Sale price $1,495.00 AUD
Sale Call For Availability
Taxes included. Shipping calculated at checkout.
  • Full Aussie Manufact. Warranty
  • Free Shipping over $500

Arcam A5 Integrated Amplifier

Quality + Connectivity = Accessible Hi-Fi

The ARCAM A5 is for those intimate listening experiences with your favourite music.

With a history spanning more than 45 years in amplifier design, ARCAM's core competence lies in amplification, as demonstrated by their latest product, the A5. Every component and material used has been carefully evaluated to guarantee exceptional sound quality, building upon their first product, the A&R Cambridge A60 amplifier, released in 1976.

So you can play music straight out of the box, the ARCAM A5 includes a Bluetooth solution with Qualcomm AptX Adaptive technology. This provides up to 24-bit HD audio for the best sound quality from your phone or tablet, no matter what you are playing.

The A5 also connects to Bluetooth headphones, so your listening experience can continue sensitively after dark.

High-res audio is included, along with high-resolution digital audio inputs.

Like any ARCAM integrated amplifier, we pay particular attention to the built-in phono stage to ensure your records sound as lush and engaging as possible.

Product Features

  • ARCAM Class AB amplification provides brilliant musicality
  • 50W per channel (8Ω) powers loudspeakers with ease
  • Bluetooth with aptXTM adaptive technology—for the best sound with the most convenience
  • Specially selected components and materials—to deliver on sound quality
  • Wired or Wireless headphones: connect your headphones for quiet listening with or without wires
  • All new Radia design: purposeful yet playful
  • MM phono stage, ready for Turntables
  • Hi-Res Digital Audio Inputs
  • Plastic-free packaging for easy disposal of natural materials

Technical Specifications

Continuous power output (0.5% THD), per channel
2 channels driven, 20Hz–20kHz, 8Ω 50W
2 channels driven, 1kHz, 4Ω 75W
Harmonic distortion, 80% power, 8Ω at 1 kHz, 0.003%

Analogue Inputs
Number of inputs: 3 (RCA pairs)
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 106 dB
Frequency response: 20Hz–20kHz ± 0.2dB

Phono (MM) Input
Input impedance: 47kΩ + 100pF
Frequency response (ref. RIAA curve): 20Hz–20kHz ± 1dB

Digital Inputs
Supported Sample Rates (kHz)
Coaxial (RCA) 192, 176.4, 96, 88.2, 48, 44.1
Optical (Toslink): 192, 176.4, 96, 88.2, 48, 44.1

Bit depths (bits): 24, 16
Frequency response (fi lter 1): 20Hz–20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 109dB

Headphone Output
Maximum output level (RMS) into 32Ω/300Ω 2.5V/5V
Load range: 16Ω–2kΩ

Mains voltage: 100V, 110–120V or 220–240V, 50–60Hz
Power consumption (maximum): 350W
Power consumption (standby): <0.5W
Dimensions W x D (including speaker terminals) x H (including feet): 431 x 344 x 83mm
Weight (net): 8kg
Weight (packed): 11kg

5 years

Supplied accessories
Mains lead(s)
Remote control with 2 x AAA batteries
Quick Start Guide
Important Safety Instructions

*This information has been obtained from Manufacturers website. We advice that Features & Specifications are subject change from Manufacturer without notice.
