Arcam A25 Integrated Amplifier
"WE ASSURE YOU THAT ALL OUR PRODUCTS ARE 100% GENUINE AND COME WITH A FULL AUSTRALIAN WARRANTY."
Arcam A25 Integrated Amplifier
Sublime Musicality + Rich Features = Your Ultimate Music System
The rich feature set includes a USB-C input for your laptop, be it PC, Mac, or Raspberry Pi! This augments a Bluetooth solution that includes Qualcomm AptX Adaptive technology with 24-bit HD audio to ensure the best sound quality no matter what you are playing. It can also connect to Bluetooth headphones, so your listening experience can continue sensitively after dark.
Like any ARCAM integrated amplifier, we pay particular attention to the built-in phono stage to ensure your records sound as lush and engaging as possible.
Product Features
- ARCAM Class G amplification—for ultra-low distortion
- 100W per channel (8Ω) powers loudspeakers effortlessly.
- Bluetooth with aptXTM Adaptive Technology—for the best sound with the most convenience
- Specially selected components and materials—to deliver on sound quality
- Wired or Wireless headphones: connect your headphones for quiet listening with or without wires
- All new Radia design: purposeful yet playful
- MM phono stage, ready for Turntables
- Hi-Res Digital Audio Inputs, with the addition of USB-C for ultra-Hi-Res audio
- Plastic-free packaging for easy disposal of natural materials.
Technical Specifications
Continuous power output (0.5% THD), per channel
2 channels driven, 20Hz–20kHz, 8Ω 100W
2 channels driven, 1kHz, 4Ω 165W
Harmonic distortion, 80% power, 8Ω at 1 kHz, 0.002%
Analogue Inputs
Number of inputs: 3 (RCA pairs)
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 106 dB
Frequency response: 20Hz–20kHz ± 0.2dB
Phono (MM) Input
Input impedance: 47kΩ + 100pF
Frequency response (ref. RIAA curve)
20Hz—20kHz ± 1dB
Digital Inputs
Supported Sample Rates (kHz)
USB-C 384, 352.8, 192, 176.4, 96, 88.2, 48, 44.1
Coaxial (RCA) 192, 176.4, 96, 88.2, 48, 44.1
Optical (Toslink): 192, 176.4, 96, 88.2, 48, 44.1
Supported DSD USB-C only: 1024, 512, 256, 128, 64
Bit depths (bits): 32, 24, 16
Frequency response (filter 1): 20Hz–20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 110dB
Headphone Output
Maximum output level (RMS) into 32Ω/300Ω 2.5V/5V
Load range: 16Ω–2kΩ
General
Mains voltage: 100V, 110–120V or 220–240V, 50–60Hz
Power consumption (maximum): 500W
Power consumption (standby): <0.5W
Dimensions W x D (including speaker terminals) x H (including feet): 431 x 344 x 83mm
Weight (nett): 9 kg
Weight (packed): 12 kg
Supplied accessories
Mains lead(s)
Remote control with 2 x AAA batteries
Quick Start Guide
Important Safety Instructions
*This information has been obtained from the manufacturer's website. We advise that features & specifications are subject to change from the manufacturer without notice.
E&OE
