AMC XIA 50 Integrated Stereo Amplifier

Punching well above its weight, both in terms of output and price point, the AMC XIA50 is the next step up from the excellent entry-level XIA30 amplifier.

Phono Stage

Tone Controls
The XIA50 incorporates a specially designed passive tone control circuit to give natural sound quality. The tone control stage can be completely by-passed with the Direct switch to give natural sound quality.

High Quality Components
The XIA50 is equipped with audiophile-grade components for physiological precision and powerful low-volume sound reproduction. Tone control and phono responses are precise and dynamic.

High Current
The XIA50 features 50 Amp high peak output devices and an optimised power supply design, granting it the ability to provide dynamic drive and consistently deliver high currents to passive speakers.

Its output stage, designed with perfect virtual image topology, allows direct connection to speakers without reliance on relay contacts, further optimising sound quality.

Toroidal Transformer
No amp is complete without a competent power supply section and a robust toroidal transformer able to provide the continuous power needs of the amplifier circuit. The universal power transformer in the XIA50 has an international safety compliance and exhibits exceptionally low RF noise to provide the ultimate in crystal clear sound.

Gold Connectors
Gold plated RCA connectors & binding post speaker terminals provide reliable sound transmission to and from the AMC XIA50 Integrated Stereo Amplifier.

About AMC

AMC is actually responsible for some of the very best brands on the market today. In fact, AMC’s failure rate is so low that most companies would only dream of.

AMC is a state of the art design and engineering company as well as manufacturer of high end Hi-Fi components. Combined with their design philosophy focusing on  25 years of reliability and state of the art manufacturing facility - as far as value for money is concerned, you get bang for buck and then some.

Peter Bath and Malcolm Blockley, both previously part of NAD, Acoustic Research and Proton, have used the cost-effectiveness of AMC's "common-platform" product design and production processes to create a product range that fulfils all of an audiophile's expectations at an attractive price point.

Features & Specifications

• Remote Controlled (sold separately) Stereo Integrated Amplifier
• Rated Power into 8 Ohm (Both Channels Driven): 50 Watts
• Rated Power into 4 Ohm (Both Channels Driven): 60 Watts
• Rated T.H.D. (Total Harmonic Distortion) 20Hz-20kHz: 0.05%
• Input Sensitivity for 1W/Rated Power into 8 Ohms
  • High Level Inputs: 23mV/150mV
  • Phono Input MM: 0.5mV/2.7mV
  • Phono Input MC: 0.05mV/0.27mV
• Input Impedance
  • High Level Inputs: 20K ohms
  • Phono Input MM/MC: 47K Ohms/100pF
• Frequency Response
  • Tone Bypass: 20-20kHz: +/-0.5dB
  • Normal: 20-20kHz: +/-1.0dB
  • High Level Inputs -3dB: 10Hz/60kHz
• Signal To Noise Ratio (1W/8 Ohms)
  • High Level Inputs A WTD: 88dB
  • Phono Input A WTD: 80dB
  • Separation 20-20KHz >65dB
• Tone Control Range
  • Bass at 100Hz: +/-10dB
  • Treble at 10kHz: -8/+11dB
  • Overall Feedback: 26/29dB
• Three Line Level Inputs
• Switchable Moving Magnet/Moving Coil Phono Input
• ¼” (6.35mm) Headphone Output
• Speaker Binding Posts which can accept Banana Plugs, Spades or Bare Wire
• Tone Controls with Direct Switch to bypass them
• Tape Monitor Circuit
• Pre Out/Power In
• Balance Control
• Front Panel Mute
• Comprehensive Remote Control  (sold separately)
• Removable Power Cable: Upgrade to an IsoTek Power Cable for better performance
• Available Finishes: Black or Silver
• Dimensions (WxHxD): 430 x 82 x 288mm
• Weight : 6.8kg
• Manufacturer’s Warranty: 3 Years
